| SPECIFICATIONS |
- Material
Internal/SUS#304
3t & 4t
External/ Double painting & baked spec
Glass/ Tempered safety glass 10t
Pecking/ Molded High Temp.
Silicone Rubber
Insulation/ Ceramic wool
Tray/ SUS plate
- Heater
Wide plate type Aluminium block heater
- Controller
P.I.D-Auto tuning with pt-100
- Over load control
250C
- Temperature Range
Ambient +5C ~150C
Heat up time : Ambient
to 100C within 60min 100C
to 250C within 80min
- Vacuum
range/0~70mmHg
|
|
|
| SPECIFICATIONS II |
|
Model No.
|
17-VDO-25
|
17-VDO-35
|
| ..Out
Dimension(W X D X H) |
70X48X50(cm)
|
72X55X55(cm)
|
| ..In
Dimension(W X D X H) |
30X30X35(cm)
|
35X35X40(cm)
|
| ..Power |
220V/ 1.2kW
|
220V/ 1.8kW
|
| ..Temp.
Controller |
Digital Display PID Type
|
| ..Temp.
Accuracy |
±0.5C at 100C
|
| ..Temp.
Range |
50C ~ 200C
|
| ..Capacity |
30L
50L
|
| ,,Shelves |
2EA
3EA
|
|
|
